For cable entry into the base/plinth. With a 200 mm base/plinth height, one or two trim panels with brush strips may optionally be used. With the optional panel attachment, the trim panels with brush strips can also be mounted on the side of the base corner piece.
VX Base/Plinth Trim Panels with Brush Strip, Carbon Steel
Rittal VX base/plinth trim panels with brush strip are designed for cable entry into the base/plinth while helping close the opening around routed cables. With a 200 mm-high base/plinth, one or two brush-strip trim panels may be used depending on the required cable-entry configuration.
Need the correct article number? Send SUWI Auto your enclosure type, required width/depth, base height and quantity for model verification and quotation support.
Cable Entry
Provides a practical cable-entry opening through the base/plinth while helping close the surrounding gap.
Flexible 200 mm Configuration
A 200 mm-high base/plinth can use one or two 100 mm-high brush-strip trim panels.
Front, Rear or Side Installation
With the optional trim panel attachment, the brush-strip panel can also be installed at the side of the base/plinth corner piece.
| Product type | Base/plinth trim panels with brush strip |
| System | Base/plinth system VX |
| Version | With brush strip |
| Trim panel material | Carbon steel |
| Brush strip material | Plastic, self-extinguishing |
| Color | RAL 9005 |
| Panel height | 100 mm |
| Packaging unit | 2 pc(s). |
| Customs tariff number | 94039910 |
Depending on the selected article number, this product family is suitable for multiple Rittal enclosure platforms:
Select the article number according to the enclosure width/depth. All versions below are 100 mm high and finished in RAL 9005.
| Article No. | Height | For Width/Depth | Version |
|---|---|---|---|
| VX 8660092 | 100 mm | 600 mm | With brush strip |
| VX 8660093 | 100 mm | 800 mm | With brush strip |
| VX 8660094 | 100 mm | 1000 mm | With brush strip |
| VX 8660095 | 100 mm | 1200 mm | With brush strip |
The integrated brush strip allows cables to pass through the base/plinth while reducing the open gap around the cable bundle. This is useful for installations where cable entry is routed from below the enclosure.
For a 200 mm-high base/plinth, one brush-strip trim panel may be combined with another 100 mm trim panel, or two brush-strip trim panels may be used where greater cable-entry capacity is needed.
For installation in the depth or on the side of the base/plinth corner piece, the optional trim panel attachment is required.
Confirm these points:
Documentation and approvals may vary by article number. Verify the selected model before ordering.
Q: What are VX base/plinth trim panels with brush strip used for?
A: They are used for cable entry through the VX base/plinth while helping close the opening around routed cables.
Q: What panel height is available?
A: The brush-strip trim panels in this product family are 100 mm high.
Q: Can they be used with a 200 mm-high base/plinth?
A: Yes. One or two brush-strip trim panels may be used with a 200 mm-high base/plinth depending on the required cable-entry arrangement.
Q: Which article number fits an 800 mm width or depth?
A: VX 8660093 is the 100 mm-high brush-strip trim panel for 800 mm width/depth.
Q: Can the panel be installed on the side?
A: Yes. Side or depth-wise installation requires the optional trim panel attachment.
Q: Can SUWI Auto verify the correct model?
A: Yes. Provide the enclosure type, required width/depth, base height and quantity and SUWI Auto can help verify the article number.
