The AX wall-mounted enclosure with embossed enclosure cams in the roof, base and side replicates the familiar 25 mm system grid from the VX25 large enclosure. Thanks to this unique, patented system, AX wall-mounted control enclosures are prepared for all expansion and retrofit cases. System components and accessories can be installed and retrofitted easily, quickly and safely on rails without drilling.
Item No :
AX 1054000Material :
Carbon SteelColor :
RAL 7035
The Rittal AX 1054000 is a large square-format carbon steel wall-mounted enclosure for control systems that need substantial mounting area in both directions. Its 600 × 600 × 250 mm body provides more depth for device projection, wiring ducts and service clearance than 210 mm AX housings, while IP66 sealing and IK10 impact resistance support demanding industrial locations.
Need pricing or availability? Contact SUWI Auto with your required quantity and delivery destination for model verification and quotation support.
| Article no.: | AX 1054000 |
| Dimensions | Width: 600 mm Height: 600 mm Depth: 250 mm ( Width: 23.6 ˝ Height: 23.6 ˝ Depth: 9.84 ˝ ) |
| Benefits |
|
| Material | Housing: Carbon steel Door: Carbon steel, all-round foamed-in PU seal |
| Surface finish | Housing and door: Dipcoat primed, powder-coated on the outside, textured paint Mounting panel: Zinc-plated |
| Color | RAL 7035 |
| Supply includes | Housing with door(s) Flange (gland) plate(s) in enclosure base Mounting panel Punched door strip Lock: 3 mm double-bit |
| Protection category NEMA |
|
| Protection category IP to EN 60 529 | IP 66 |
| Type rating according to UL 50E |
|
| IK code | IK10 |
| Material thickness - door | 1.5 mm ( 0.06 ˝ ) |
| Material thickness - enclosure | 1.5 mm ( 0.06 ˝ ) |
| Material thickness – mounting plate | 2.5 mm ( 0.1 ˝ ) |
| Dimensions of mounting plate (W x H) | 550 mm x 575 mm ( 21.7 ˝ x 22.6 ˝ ) |
| Number of doors | 1 |
| Interchangeable door catch | Yes |
| No. of locks | 2 |
| Lock | Lock version: Cam No. of locks: 2 Lock Insert: 3 mm double-bit |
| Gland plate | Size: 4 Qty.: 1 |
| Base material | Carbon steel |
| Packaging unit | 1 pc(s). |
| Net weight | 23.278 kg |
| Gross weight | 23.4 kg |
| PCF/VE (cradle-to-gate) | 93.7 kg CO2 eq (Cat B) |
| Information regarding the PCF class | Category B: PCF value (cradle-to-gate) calculated approximately on the basis of the product weight and self-declared |
| Customs tariff number | 94032080 |
| EAN | 4028177813328 |
| ETIM 9 | EC000261 |
| ETIM 8 | EC000261 |
| ECLASS 8.0 | 27180101 |
When a Larger Square Panel Needs More Than 210 mm Depth
AX 1054000 provides a 550 × 575 mm mounting panel for several horizontal device rows, side-by-side functional groups or a divided power-and-control layout. The 250 mm enclosure depth adds 40 mm over shallower AX models, giving more room for projecting components, duct covers and cable bends while retaining a wall-mounted format.
Choose AX 1050000 when a 500 × 500 mm front area and 210 mm depth can accommodate the complete assembly. Choose AX 1037000 when the design needs greater vertical capacity and 300 mm depth rather than a broad square panel. Before machining AX 1054000, verify the 550 mm usable width, both lock positions, cable routing through the size 4 base opening and clearance between deep devices and door-mounted controls.
Use this supply list to separate the included enclosure components from optional interior-installation and cable-entry parts:
The standard configuration includes a 550 × 575 mm mounting panel and one size 4 gland plate in the enclosure base. Define cable quantity, outside diameter and connector dimensions before selecting an alternative entry plate.
AX 1054000 requires interior rails made for 250 mm enclosure depth and replacement entry plates matching gland-plate size 4. Plan the wide cable-entry area around incoming cable groups, connector diameters and any required separation between power and control wiring.
2394250 Rail for Interior Installation AX
Suitable for enclosure type: AX
Suitable for depth: 250 mm
Packaging unit: 4 pc(s).
2394100 Base configuration rail
Suitable for enclosure type: AX
Packaging unit: 1 pc(s)
2564300 Plastic Cable Gland Plate with Diaphragms
Size: 4
Width: 534 mm
Depth: 149 mm
2503020 Wall Mounting Bracket
Material: Carbon steel, zinc-plated Wall distance: 40 mm Suitable for enclosure type: AX / KX / AX wall-mounted housing, 3-part
Packaging unit: 4 pc(s)
4052000 Multitool
Packaging unit: 1 pc(s)
Plastic Wiring Plan Pocket
Packaging unit: 1 pc(s)
Ground Straps
Packaging unit: 8 pc(s)
2519020 Door stay
Packaging unit: 1 pc(s)
Planning a high-capacity AX 1054000 assembly? Send the mounting-panel drawing, deepest component, duct dimensions, cable-entry schedule and proposed door cut-outs so the 250 mm depth and working clearances can be reviewed before machining.
AX 1054000 provides a 600 × 600 × 250 mm enclosure with a 550 × 575 mm mounting panel. Compare AX 1050000 when the project can use a smaller square front and 210 mm depth, or AX 1037000 when vertical mounting height and 300 mm depth matter more than panel width. Base the change on usable area, component projection and cable-bend requirements.
View AX Carbon Steel Enclosures →
The AX wall-mounted enclosure with embossed enclosure cams in the roof, base and side replicates the familiar 25 mm system grid from the VX25 large enclosure. Thanks to this unique, patented system, AX wall-mounted control enclosures are prepared for all expansion and retrofit cases. System components and accessories can be installed and retrofitted easily, quickly and safely on rails without drilling.
