The AX wall-mounted enclosure with embossed enclosure cams in the roof, base and side replicates the familiar 25 mm system grid from the VX25 large enclosure. Thanks to this unique, patented system, AX wall-mounted control enclosures are prepared for all expansion and retrofit cases. System components and accessories can be installed and retrofitted easily, quickly and safely on rails without drilling.
Item No :
AX 1110000Material :
Carbon SteelColor :
RAL 7035
The Rittal AX 1110000 is a large square-format double-door carbon steel wall-mounted enclosure for control systems that need extensive horizontal and vertical mounting capacity in one cabinet. Its 1,000 × 1,000 × 300 mm body provides a 945 × 975 mm mounting area for multiple rows and side-by-side functional sections, with IP55, NEMA 1/12, UL Type 1/12 and IK10 ratings for protected industrial installations.
Need pricing or availability? Contact SUWI Auto with your required quantity and delivery destination for model verification and quotation support.
| Article no.: | AX 1110000 |
| Dimensions | Width: 1,000 mm Height: 1,000 mm Depth: 300 mm ( Width: 39.4 ˝ Height: 39.4 ˝ Depth: 11.8 ˝ ) |
| Benefits |
|
| Material | Housing: Carbon steel Door: Carbon steel, all-round foamed-in PU seal |
| Surface finish | Housing and door: Dipcoat primed, powder-coated on the outside, textured paint Mounting panel: Zinc-plated |
| Color | RAL 7035 |
| Supply includes | Housing with door(s) Flange (gland) plate(s) in enclosure base Mounting panel Punched door strip Lock: 3 mm double-bit |
| Protection category NEMA |
|
| Protection category IP to EN 60 529 | IP 55 |
| Type rating according to UL 50E |
|
| IK code | IK10 |
| Material thickness - door | 2 mm ( 0.08 ˝ ) |
| Material thickness - enclosure | 1.5 mm ( 0.06 ˝ ) |
| Material thickness – mounting plate | 2.5 mm ( 0.1 ˝ ) |
| Dimensions of mounting plate (W x H) | 945 mm x 975 mm ( 37.2 ˝ x 38.4 ˝ ) |
| Number of doors | 2 |
| Interchangeable door catch | Yes |
| No. of locks | 2 |
| Lock | Lock version: Cam No. of locks: 2 Lock Insert: 3 mm double-bit |
| Gland plate | Size: 6 Qty.: 2 |
| Base material | Carbon steel |
| Packaging unit | 1 pc(s). |
| Net weight | 64.5 kg |
| Gross weight | 65 kg |
| PCF/VE (cradle-to-gate) | 213.84 kg CO2 eq (Cat B) |
| Information regarding the PCF class | Category B: PCF value (cradle-to-gate) calculated approximately on the basis of the product weight and self-declared |
| Customs tariff number | 94032080 |
| EAN | 4028177813212 |
| ETIM 9 | EC000261 |
| ETIM 8 | EC000261 |
| ECLASS 8.0 | 27180101 |
When the Layout Needs Full-Height Left and Right Sections
AX 1110000 provides a 945 × 975 mm mounting panel that can be divided into two tall functional sections or several wide equipment rows. Its square format avoids forcing a large assembly into a narrow vertical column, while the 300 mm depth leaves more front-to-back working space than shallow 210 mm AX cabinets.
Choose AX 1096000 when the same 1,000 mm cabinet width and 300 mm depth are required but 575 mm of panel height is enough. Choose AX 1100000 when a 945 × 735 mm panel can hold the design and reducing depth to 210 mm is more important. Before machining AX 1110000, finalize the complete row schedule, define the left/right functional boundary, assign each door cut-out to its leaf, preserve central meeting and lock clearances, and map incoming cables to the two size 6 base-entry zones.
Use this supply list to separate the included enclosure components from optional interior-installation and cable-entry parts:
The standard configuration includes a 945 × 975 mm mounting panel and two size 6 gland plates in the enclosure base. Define cable quantity, outside diameter and connector dimensions for each entry zone before selecting alternative plates.
AX 1110000 uses interior rails specified for 300 mm enclosure depth and replacement entry plates matching gland-plate size 6. Coordinate the two base-entry zones with the left and right functional sections so cable groups rise directly toward their assigned panel area.
2394300 Rail for Interior Installation AX
Suitable for enclosure type: AX
Suitable for depth: 300 mm
Packaging unit: 4 pc(s).
2394100 Base configuration rail
Suitable for enclosure type: AX
Packaging unit: 1 pc(s)
2566300 Plastic Cable Gland Plate with Diaphragms
Size: 6
Width: 401 mm
Depth: 221 mm
2503020 Wall Mounting Bracket
Material: Carbon steel, zinc-plated Wall distance: 40 mm Suitable for enclosure type: AX / KX / AX wall-mounted housing, 3-part
Packaging unit: 4 pc(s)
4052000 Multitool
Packaging unit: 1 pc(s)
Plastic Wiring Plan Pocket
Packaging unit: 1 pc(s)
Ground Straps
Packaging unit: 8 pc(s)
2519020 Door stay
Packaging unit: 1 pc(s)
Planning a large AX 1110000 assembly? Send the mounting-panel drawing with complete row schedule and functional boundaries, deepest component, vertical duct dimensions, cable allocation for both size 6 base plates, and door cut-outs identified by leaf so the 945 × 975 mm panel can be reviewed before machining.
AX 1110000 provides a 1,000 × 1,000 × 300 mm double-door enclosure with a 945 × 975 mm mounting panel. Compare AX 1096000 when the same width and depth are needed but 575 mm of panel height is sufficient, or AX 1100000 when a 735 mm-high panel can hold the design and a shallower 210 mm body is preferred. Base the change on vertical row count, functional zoning, component projection and available wall height.
